Past Section Meetings
June 2015 Meeting Summary
Our June 18th section meeting took place at the WBNS Digital Television Plant in Columbus, with 45 members and guests in attendance. Our guest presenter for the evening was Kenneth Hunold, Staff Engineer, Audio Production, from the Dolby Laboratories Inc. East coast offices, New York City. Ken started out his topics by going over the many Dolby Labs technologies and innovations developed over the past 50 years, which helped reshape the audio engineering landscape in various forms in key media industries such as, music recording, motion picture studio sound, cinema sound presentation formats, radio and television audio broadcasts, to name a few. He also showed the group various video/audio clips of key engineers/inventors within the Dolby organization who were explaining some of their products and designs over the years such as, an interview with their founder, the late Ray Dolby, and other creative staff engineers within their organization! He went on to present several video/audio clips detailing their new multi-channel surround audio format called, Dolby ATMOS, and in the field of video, a new wider pipeline, color gamut, and luminous channel technology format called, Dolby Vision. These two technologies are starting to appear in new dedicated cinema houses around the world, as well as the possibility of being included in the next generation broadcast standard in the USA referred to as, ATSC 3.0. Ken also discussed some of the new mobile devices now and in the future, which will employ Dolby ATMOS technologies in a more personable form. The meeting host, WBNS-DT is also significant for Dolby Labs because of the fact that Dolby Digital 5.1 audio broadcasting was pioneered by the station as part of their historic September 5th, 1998, remote HD telecast of an Ohio State University Buckeyes football, away game.
A lively Q & A session followed, Ken's well received presentation!
Gene L. Batey,
May 2015 Meeting Summary
The May 28th section meeting was combined with the local SBE Chapter 52, and took place at the WBNS Digital Television Plant in Columbus, with approximately 40 members/guests in attendance. The guest presenter for the evening was Timothy B. Anderson, CPBE Manager, Radio Market and Product Development, at GatesAir. His topic was the history of High Fidelity radio broadcasting, in the USA. Tim began his presentation at the starting point in 1932 with the application for the first experimental APEX AM Hi-Fi radio station license by CBS radio, in New York City. For the first time then the Experimental High Fidelity radio stations could transmit wider bandwidth signals from high points/towers which sounded more "life like, just like sitting in the concert hall" to specially equipped radios, some of which were even homemade, before regular commercial production took place. After an experimental period of around ten years, the FCC orders them to move over to the (then) new FM band, eventually becoming regular commercial Hi-Fi stations, and re-assigned to new frequencies, simulcasting alongside of their standard AM stations. He then traces some of the later Hi-Fi radio innovations to the TV industry such as, eventually using FM for the audio portion of the Television broadcasting channel. Tim then lists several of the AM/FM stereo radio broadcasting techniques developed and tested, which led to the standardized FM stereo multiplex system. He goes on to point out that with the eventual launching of a hybrid Digital radio broadcasting system or HD, it was then possible to transmit additional programming streams of data such as for still graphics, and other types of visual signals, and even several additional/separate audio program streams, all within the same frequency! One of his predictions for HD Hi-Fi radio broadcasting services included the possibility of some all digital AM stations, which will not be backwards compatible with those on the air today, in order to more fully utilize the AM band.
A lively Q&A session followed.
From L-R: John Owen, SMPTE Ohio Section-Chairperson, Timothy Anderson, GatesAir
Timothy Anderson, GatesAir, presenting to the members/guests
Meeting host site at the WBNS Digital Television Plant, Columbus
April 2015 Meeting Summary
Our April 30th section meeting was combined with the local Society of Broadcast Engineers Chapter 52, and took place at the Mills-James production lot in Columbus. 40 members and guests were in attendance to see and hear several very interesting, informative and comprehensive presentations, covering the highlights of the recent NAB Conference/Show in Las Vegas, Nevada. The guest presenters for the evening were from the technical Architecture and Engineering consulting firm of Osborn Engineering, in Cleveland, which included, Don Archiable-Vice President and Director of Technology, Tyler Slentz-Technology Designer, and Mark Fehlig-Senior Engineer RF Spectrum. Each of their presentations covered a multitude of topics such as, 8K, 4K, UHD 2, new compact camera designs and lenses, as well as smaller mounting and trucking devices for them, and new and improved large panel screens and projection displays, just to name a few. They also discussed some of the expected features to be included in the proposed ATSC 3.0 broadcast standard of the future in the USA such as, the proposed superior COFDM terrestrial Television transmission standard features and the fact that it's not "backwards compatible" with the current 8 VSB standard, and the proposed FCC spectrum auction time tables which could lead to some future TV station repacks involving possible channel/tower sharing arrangements, etc. A very lively Q &A session followed. The generous refreshments for the meeting were also furnished by Osborn Engineering!
Tyler Slentz, Don Archiable and Mark Fehlig all from Osbourne Engineering were presenters at the combined Ohio Section/SBE Chapter 52 April 2015 meeting.
November 2014 Meeting Summary
The November 18th, 2014 section meeting took place at the Lyon Video lot in Columbus, with approx. 25 members/guests in attendance. This special all day seminar-meeting was co-sponsored by Tektronix, and AVI. Karl Kuhn, Senior Video Systems application Engineer at Tektronix, was the lecturer/presenter for the day, covering a multitude of very timely broadcast industry topics including: video transmission chain review, time code-LTC, VITC, ANC, TC, and NTP, test equipment justification process, gamut/camera shading, closed captioning, ANC data troubleshooting, 4K Ultra HD and 8K realities, the calm act, and adaptive but rate. He also went into more detail in topic areas such as, understanding the fundamentals of a stable quality focused facility that stays away from the digital cliff, future technology trends, and implementation concerns from acquisition, to end user. The seminar also included periodic and lively Q&A sessions, along with the attendees. Complementary breakfast and lunch/snacks were served during the day, and early evening sessions.
June 2014 Meeting Summary
The June 26th, 2014 section meeting was combined with the local SBE Chapter 52, and held at the Bennet Systems Inc. remote truck assembly factory in Sunbury, Ohio. Twelve members and guests were treated to a rare opportunity to view a pre launch of the new Lyon Video MU-14 remote truck of the future. A special pre-tour power point presentation was given first by the Evertz Microsystems Ltd. Regional Sales Manager, Kyle Miobertolo, who went over the new futuristic Magnum Unified Control System, which is installed in the remote truck. The Evertz Magnum 4K/8K over IP routing system, bridges all of the major components within the broadcast path under a single point of control, enabling broadcasters to simplify facility workflow and gain efficiency, while reducing operational costs. This is accomplished through unifying the control and operation of the routing core, master control, production, switching, advanced transport and multi-viewer, which make up the core elements of the production truck. From there the group moved to the final assembly area, where the finishing touches were being made. A lively Q&A exchange took place between the various members/guests and Barry Bennett, the CEO/owner of Bennett Systems, the prime contractor for the project, who was guiding the tour. The Lyon Video remote truck is expected to be launched later this Summer, and go online this coming fall, in time for various sports coverage broadcasts.
Barry Bennett-Bennett Systems Inc. guiding the tour!
SMPTE and SBE members on the tour.
The Evertz Magnum 4K/8K over IP router "brain"
(From L-R) Ed Shrider - A SMPTE Ohio Section Manager, Kyle Miobertolo, Evertz Regional Sales Manager
Barry Bennett concluding the tour of the new van.
May 2014 Meeting Summary
Our May 15th, 2014 section meeting was combined with the SBE Chapter 52, and held at the Mills James Productions lot in Columbus. 25 members and guests were in attendance for two very well received topics such as, the 130 year history of the firm Osborn Engineering, and the top ten displays/topics featured at this year's NAB conference/show. The guest presenters for the evening were Don Archiable, a Technology designer from the Cleveland office of Osborn Engineering, and Assisting in the presentation was Tyler Slentz, also a technology designer with the firm. Don started out with a historical outline of the many stadiums the firm has designed over the decades such as, Yankee Stadium, Wrigley Field, and even The Ohio State University "horse shoe" stadium! He mentioned that today's modern stadium designs must include not only complete high end video/scoreboard type displays, but also the latest designs of both fixed and moveable video cameras, and audio pick ups, and a requirement for a comprehensive wireless infrastructure to be in place to handle all of the current, as well the expected future, wireless communications needs! Tyler then gave an overview of the top ten most innovated displays at the recent NAB such as, a 4K/8K UHD-HD image comparison demonstration. He also showed a graphic of the expected broadcast Video/AUDIO/IT facilities of the future, where conventional scattered/segregated TV/radio/newspapers/studio and news operations, will all be part of just one large "one roof" type IT platform, thus reducing redundancy of operations, as well as costs. A lively Q&A session, followed their presentation!
Don Archiable and Tyler Slentz, Osborn Engineering and Ohio SMPTE Chairman, John Owen (L-R)
February 2014 Meeting Summary
Our February 26th, 2014 section meeting took place at the WBNS Digital Television Plant, in Columbus, where 40 members/guests attended an outstanding and informative presentation by Ken Hunold, from The Dolby Labs-east coast office, New York City. Ken opened his presentation outlining and discussing the history of Television broadcasting service in the United States, and specifically the various audio formats which have been used. He began with TV broadcasting's official launch at the 1939 New York World's Fair, and went through various audio enhancements introduced over the years, leading to what we are accustomed to today. He also included his predictions, for TV audio broadcasts of tomorrow. He pointed out that early TV audio broadcasting actually used an AM type RF signal in the chain, which had to be routed through a separate radio set, via a phono plug type patch cable, from the TV set. This was later changed to a FM type signal format, which was then included within the TV set cabinet itself. He traced some of the various types of TV audio broadcasting enhancements which were introduced over the decades such as, two channel matrix MTS, Dolby ProLogic Surround, which included a bass reflex channel. He added that a major improvement to TV audio performance occurred with the FCC mandated change over to the ATSC 1.0 digital TV broadcasting standard, which included the Dolby Digital 5.1 Surround audio format. That innovation resulted in viewers then having a multi channel audio experience at home, more closely replicating the typical one heard in a movie theatre. A few minutes of a Sept. 1998 Ohio State Football game telecast produced by WBNS-Digital HD Television was played back, which launched the first Dolby Digital 5.1 surround audio broadcast. He also played back a special presentation going through the history and basics of a movie theatre sound system, as well as a new process introduced last year called, Dolby Atmos, which can provide up to 64 independent speaker channels from a 128 track mixed movie master. Some of those speakers are even placed in the ceiling over the audience, thus creating a more "immersion experience." This allows an audience the ability to actually isolate specific "audio objects" around the auditorium! He predicted that TV audio formats of the future will also include more surround channels/speakers in the consumer's home theatre setting such as, 9.1, 11.1, in an effort to match the expected viewing enhancements created by future TV video standards such as, 4K, higher frame rates, greater color gamuts, curved TV screens, to name a few. A very lively Q & A session followed.
Ken Hunold, Staff broadcast applications Engineer at Dolby Labs, addressing the Ohio Section meeting attendees
From L-R: Pat Ingram-Chief Engineer WBNS Television, John Owen-SMPTE Ohio Section ChairPerson, Ken Hunold-Dolby Labs-guest presenter, Gene Batey-Ohio Section Sec./Treas
From L-R: John Owen-Ohio Section Chairperson, recruiting past SMPTE member Steve Carr, to re-join!
January 2014 Meeting Summary
Our January 30th, 2014 evening section meeting took place at the Mills-James Creative media video production lot, in Columbus, with twenty-five members and guests in attendance. It was a combined meeting along with the central Ohio SBE chapter 52. Mr. Victor Brewer, from the firm of Aerial Image Solutions, in Galena Ohio, made a very interesting and well received presentation discussing his company’s new and innovative approach to aero photography, utilizing a smaller than usual version of an air Drone called, the UAV. What sets it apart from other versions of aero imaging craft being used today, are the unique designs of its propeller motors, featuring smaller blades, as well as the power plant battery, and camera mount stabilizer. It has the capability of up to 25 minutes in the air, and is very safe for both the general public, as well as for the operator of the craft! After Mr. Brewer’s initial presentation, the meeting was moved to Studio “B” of the facility, for an exciting live demonstration of the craft! The Drone’s versatility was pointed out as offering a device which can deliver a wide range of field environmental settings for any type of aero photography service needs including, an indoor studio/stage environment, or for an outdoor field use, as well. The camera stabilizer mounts will support multiple types of camera designs including, video and still, HD, even futuristic technologies such as 4K! A very lively Q & A session, then followed.
Aerial Image Solution's new umanned aerial vehicle photo drone craft
Victor Brewer from Aerial Image Solutions holding the remote control unit for the unmanned aerial vehicle photo drone
Victor Brewer demonstrating the unmanned aerial vehicle photo drone in a studio environment
November 2013 Meeting Summary
Ohio Broadcast Engineering Conference
Greater Columbus Convention Center
The SMPTE meeting was informal with just a sign in register for lunchtime.
October 2013 Meeting Summary
Our October 15th, 2013 meeting/seminar was held along with the local SBE chapter 52, at the Lyon Video lot, in Columbus. Karl Kuhn, Senior Video Applications Engineer, Tektronix, Inc. delivered a comprehensive all day/early evening series of seminar presentations, covering all phases of video/audio chain testing and analysis. He started the morning session off with a nostalgic type 16 M.M. film produced in 1949 by RCA, which gave prospective broadcast video customers in those days, a preview of what was to become the new United States national broadcasting system. Next, he covered the basics of video/audio signal testing and how it has evolved from basic instruments such as the first generation of oscilloscopes, to digital display and analytical applications of today, and what will be needed tomorrow! He went over in detail, elements of testing such as video transmission chain review, time code, closed captioning, gamut and camera shading, to name just a few. He also outlined some of the expected industry testing needs of the future such as for 4K/8K video, and file based video/audio archival storage systems. The generous refreshments for lunch and evening breaks, were furnished by Tektronix and Lyon Video, with approximately 40 members/guests in attendance.
Karl J. Kuhn, from Tektronix, Inc.
Some of the Ohio Section members/guests during the all day Tektronix seminar.
September 2013 Meeting Summary
Our September 26th, 2013 section meeting took place at the WBNS Digital Television plant in Columbus, with 30 members/guests in attendance. Tim Anderson, Harris Broadcast Manager-of strategic Radio market and product development, from Mason Ohio, delivered a comprehensive presentation on the topic: “Terrestrial HD Radio-Past, Present, and next generation!” Tim started out by going over the earliest days of digital signaling communications in the USA, starting with the basic wired telegraph, and moving on to wireless telegraphy, and voice signaling. From that period on he then spanned a 120 year period of significant achievements in radio transmitters and designs, leading to the present day’s HD radio technology. This now includes features such as “iTunes tagging” where after a song is heard on a HD radio station, a listener can “tag” it for future purchase. Another feature he went over was “Artist Experience” which enables a HD radio broadcaster to transmit the Album cover artwork that the song, which is currently playing, was taken from, as well as sponsor and other types of promotions, all displayed on the screen of the HD radio. He also mentioned that beginning with the 2014 automobile year, all vehicles sold in the USA, will have HD radios installed as standard equipment, with all of these latest features! Finally, he outlined plans for future, next generation HD Radio broadcasts, and what those will mean for the overall survival of the terrestrial Radio broadcasting industry. A lively question and answer session followed his very interesting, and well received presentation.
SMPTE Ohio Section
May 2013 Meeting Summary
The May 16th section meeting was held at the WOSU-AM/FM/TV Public Broadcasting stations lot, located on the campus of The Ohio State University in Columbus, with 25 members & guests in attendance. The guest presenter for the evening was Kevin Bauman, President of the broadcast tower consulting firm of Paul J. Ford and Company-Structural Engineers. Mr Bauman gave an updated presentation covering the current and past structural standards for broadcast steel Antenna Towers and supporting structures, which included an outline of the five most recent years when standards/practices have been modified. A year by year comparison was outlined reflecting the various upgrades to some of the established standards, which may have changed. In some cases, the standards have shifted due to more modern data accumulation, and the resulting data hardware/software analysis, etc. One of the main standards which changed were the two which related to a tower’s ability to withstand the effects of wind and ice, especially in areas of the United states where the effects are felt the most. A slide of a computer generated wind and Ice map was presented which shows those particular areas, and how they influenced the modification of the new standards. Mr. Bauman’s well received presentation was followed by a lively, Q & A session.
SMPTE Ohio Section
April 2013 Meeting Summary
The Ohio Section meeting was combined with Society of Broadcast Engineers-Central Ohio Chapter 52, and took place at the WSYX-DT/Sinclair Broadcast Television Studio lot in Columbus, on April 25th, 2013. 40 members and guests were in attendance. The guest presenter for the evening was Jay Adrick, formerly with Harris Broadcast and after January 1st of this year, a consultant for the firm. Mr. s power point presentation outlined various cutting edge broadcast technologies currently being proposed to the FCC and Congress, which included next generation DTV broadcasting models for: Mobile DTV, Mobile EAS, and controversial issues such as the FCC proposed DTV Spectrum repacking/auction plan. Mr. Adrick also presented an overview of some of the new hardware/software technologies featured at the recent 2013 NAB conference/show in Las Vegas such as: 4K video, higher frame rates, 3D, emergency alerting. It was also that location where Jay accepted the prestigious 2013 NAB Engineering Achievement Award! A very lively Q & A session followed, his very well received presentation. A bevy of delicious refreshments were made available, throughout the meeting.
SMPTE Ohio Section
March 2013 Meeting Summary
The March 21st section meeting was held at the Mills-James productions lot in Columbus, with 27 members/guests in attendance, and combined with the Society of Broadcast Engineers, local chapter 52. The guest speaker for the evening was Scott Lanum, the M. J. Operations Chief, who gave the group a very interesting presentation on the current and future state of local, regional, and national, TV/video commercial production. Mills James is one of the top notch producers of TV/video ads in the industry, utilizing a variety of high end production techniques ranging from high end hardware/software logistics, to their highly experienced and talented in house personnel. Scott mentioned that they are now distributing video ads through an ever emerging number of venues ranging from, Broadcast/cable/sat. to online streaming. His presentation was centered around and from a technological point of view, as to where the TV/video advertising state is at the present time, and where he forecasts it to evolve, in future years. He suggested that greater effectiveness for many TV/video ads of today and tomorrow, could be achieved from adding some of the high end production techniques available such as full HD video, and 5.1 audio, resulting in more effectively grabbing a viewer’s attention, leading to more robust sales for the sponsors. A very active and interesting Q & A interaction session followed, with those in attendance. A variety of Pizzas, a garden salad, dessert, and beverages, were also offered during this very interesting and well received evening meeting!
